Power supply - DIN rail 12V DR-15-12

MEAN WELL DR-15-12 is an industrial DIN‑rail AC/DC power supply with a single regulated output, intended for reliable powering of devices such as door entry systems, access control units and other low‑voltage industrial equipment.

The unit provides a stable 12 V DC output at up to 1.25 A (15 W). It accepts a wide input range of 85–264 VAC (or 120–370 VDC), allowing use in varied mains environments.

Protection features include overload protection (OPP) with automatic recovery, short‑circuit protection (SCP) and over‑voltage protection (OVP). The compact housing (25 × 93 × 56 mm) mounts on standard TS35/7.5 or TS35/15 DIN rails and weighs approximately 0.1 kg, simplifying installation in distribution cabinets and enclosures.

Operating temperature range is -20 °C to +60 °C, and input‑to‑output isolation is 3 kVAC. The product meets relevant safety and EMC standards declared by the manufacturer, making it suitable for professional installations where compliance and reliability are required.

• Main specs: 12 V DC, 1.25 A, 15 W
• Input: 85–264 VAC / 120–370 VDC
• Mounting & size: DIN rail, 25 × 93 × 56 mm
• Protections: OPP, OVP, SCP

The DR‑15‑12 offers a compact, cost‑effective solution for powering low‑power industrial and access control devices; verify device current requirements and environmental conditions before installation.
